Wednesday, February 23, 2011

EBP Booster

EBP BOOSTER
Q3 is J-FET 2N5457
Q4 is Japanese NPN C1815.
K2 is DIP-2 Switch to select the right tone

Super Six

SUPER SIX - FENDER EMULATION AT LEVEL 6
Transistor is BS170.

Peach Fuzz

PEACH FUZZ (WITHOUT RELAY SWITCHING)
Pending verification!!!!
U1 is TCL2262
U2 and U3 are LM386N1.

Minimalist Metal Distortion


Minimalist Metal Distortion
Q1 is 2N3904 with Hfe around 225
Q2 is 2N3904 with Hfe around 170

DAM Meat Head - Remake of the one posted in pcb4diyeffects

DAM MEAT HEAD
This is remake layout of MEAT HEAD posted in pcb4diyeffects.

Q1 is 2N3904
Q2 is BC182L

The size of PCB should be able fit into small enclosure like Lovepedal Mini Series



Katana Boost

KATANA BOOST
Q1 and Q2 are J-FET 2n5484.
IC1 is charge pump IC, setup as voltage doubler here.
Extream Max power input is 10v, charge pump will double this to give the circuit with ~20v head room.


SD Pickup Booster

SD PICKUP BOOSTER
Q1 & Q2 are NPN
Q3 is PNP

This booster work very nice with OCD.
It pushed my OCD into near metal dsitortion zone, very meaty.

Wednesday, May 19, 2010

Power Grid 4x2


Power Grid 4x2 Deluxe
Stomp boxes power supply featuring 4 isolated channels with 250mA per channel.
Pads provided to daisy chain each channel to give 2 outputs, making total 8 possible outputs.
Voltage for each channel can be individually adjust from 6 to 21V.

Saturday, February 27, 2010

SuperPek - Dirty Channel - Verified.

"SuperPek" Dirty Channel
> Add a dirty channel to your single channel AMP.
> Sound very Marshall-ish.
> Very meaty when combined with ZW44 Overdrive.

Friday, October 23, 2009

SUBM Bass PreAmp - Pending Verification


SUBM BASS PREAMP

- added FET buffer. Optional to build buffered or non buffered version.

This creature will "smootherns and sweeterns the tone to give a fat and clear bass tone. It give fair amount of gain to your line level input"....you know what is this if you are a keen bass player. :)
